Features of PTFE fusing machine belt :
1. High temperature resistance -- it can continuously work
under-140 to 360°C , max resist up to 380°C.
2. Non-adhesive -- it can easily remove all kinds of adhesives such
as resin, paint and chemical medicine
3. Corrosion resistance -- it can resist acid, alkali, and various
kinds of organic liquid corrosion.
4. Good size stability -- it has high tensile strength and good
mechanical property.
5. Fireproofing and flame resistance.
6. Medicament resistant and no.n-poison.
Applications
1. Used as various of liners to resist high temperature, such as
microwave liner, oven liner, BBQ mats, food drying or other liners.
2. Used as various of PTFE high temperature conveyor belts.
3. High insulation of electric: insulating belt of electric, septa,
cushion, and gasket. High frequency plank coated with copper;
4. Heat resisting envelope, enswathing of heat insulation;
5. Binding of all sorts of petroleum and chemical pipeline to
resist eroding, environmental sulfur separating of exhaust gas of
electric factory
6. It could be made into static resisting fabric.
| Model | Color | Thickness | Max width | Weight | Tensile Strength | Temp Resistance |
| (mm) | (mm) | ( g/m² ) | (N/mm) | (°c) |
| 1008 | Brown | 0.08 | 1250 | 158±5 | 500/480/50 | -140~360 |
| 1008C | Black | 0.08 | 1250 | 160±5 | 620/460/50 | -140~360 |
| 1013A | Brown | 0.13 | 1250 | 290±5 | 910/880/50 | -140~360 |
| 1013B | Brown | 0.13 | 1250 | 215±5 | 1000/960/50 | -140~360 |
| 1013C | Brown | 0.13 | 1250 | 180±5 | 1100/900/50 | -140~360 |
| 1013G | White | 0.13 | 1250 | 290±5 | 910/880/50 | -140~360 |
| 1018G | White | 0.18 | 1250 | 310±5 | 1600/1600/50 | -140~360 |
| 1018C | Black | 0.18 | 1250 | 415±5 | 1500/1500/50 | -140~360 |
| 1025A | Brown | 0.25 | 1250 | 490±5 | 2800/2700/50 | -140~360 |
| 1025B | Brown | 0.25 | 1250 | 380±5 | 2200/2000/50 | -140~360 |
| 1025D | Brown | 0.25 | 1250 | 320±5 | 2500/2600/50 | -140~360 |
| 1025JK | Brown | 0.25 | 2250 | 490±5 | 2800/2700/50 | -140~360 |
| 1025JK2 | Brown | 0.25 | 2550 | 490±5 | 2800/270050 | -140~360 |
| 1029C | Black | 0.29 | 1200 | 400±5 | 2700/2500/50 | -140~360 |
| 1030C | Brown | 0.3 | 2600 | 520±5 | 2500/2400/50 | -140~360 |
| 1030JK | Brown | 0.3 | 2600 | 620±5 | 2800/2700/50 | -140~360 |
| 1035JK | Brown | 0.35 | 2500 | 670±5 | 2100/2000/50 | -140~360 |
| 1035JK1 | Brown | 0.35 | 2500 | 620±5 | 2200/2100/50 | -140~360 |
| 1035JK2 | Brown | 0.35 | 2500 | 560±5 | 2200/2100/50 | -140~360 |
| | | | | |
|
